3.0mm Right-Angle Wire-to-Board Connector

Key Features

The right-angle orientation allows the cable to exit parallel to the PCB rather than vertically from the board.

Available 6- and 16-circuit configurations support different board-connection capacities.

The connector is specified for 1.6mm PCB thickness.

A 3.0mm pitch supports organized contact spacing for compact electronic assemblies.

The 3.0mm Right-Angle Wire-to-Board Connector supports 0.20-0.30 mm² conductors and a 5A rated current.

Applications

The 3.0mm Right-Angle Wire-to-Board Connector is suitable for electronic equipment requiring side-entry cable routing from a PCB-mounted connection point. It can be specified for control boards, internal equipment wiring, and compact electrical assemblies where the PCB layout requires a right-angle connector.

Ordering & Quotation Information

Please provide the required model or product type, quantity, relevant technical configuration, and any drawing or packaging requirements for a quotation.

FAQ

Q1: Which circuit counts are available?
This right-angle connector is available in 6- and 16-circuit versions.

Q2: How does it differ from the vertical version?
Its cable-entry direction is parallel to the PCB, while the vertical format enters perpendicular to the board.

Q3: What PCB thickness is supported?
The confirmed applicable PCB thickness is 1.6mm.

Q4: Can you provide the matching cable assembly?
Yes. Please provide the PCB drawing, wire size, cable length, and required connector quantity.
