4.2mm Pitch Vertical Through-Hole Header

Key Features

Straight pins provide a vertical connector orientation above the PCB.

A 1.6mm PCB mounting design supports common through-hole board construction.

Available circuit counts allow one header platform to serve multiple harness widths.

White and black material options are available by selected configuration.

The header provides controlled electrical values for power and signal distribution interfaces.

Applications

Industrial control boards. Power supply assemblies.

Appliance control modules. Wire-to-board interfaces in electronic equipment.

Ordering & Quotation Information

Please provide the required circuit count, housing color, PCB thickness and mating harness requirement. Confirming the straight vertical orientation at the quotation stage helps avoid board-layout errors.

FAQ

Q1: Does every circuit count use the same waterproof plug structure?
A: The family is available in multiple circuit counts from 2 to 24. Dimensions vary with circuit count, and the required version is specified for quotation.

Q2: Which details are required for a waterproof harness assembly?
A: Confirm the plug circuit count, terminal selection, wire size and the matching sealed interface together to prevent assembly mismatch.

Q3: Can this connector be used for automotive auxiliary wiring?
A: It is suitable for protected low-voltage power and signal harness applications within its stated electrical ratings. The specified configuration should match the vehicle system’s environmental requirements.

Q4: Which wire range is supported?
A: Terminal options cover 0.2 to 0.75 mm² wire, depending on the terminal version selected.

Request a Quote

Contact us with your circuit count, wire size and sealing application details for the 4.2mm Waterproof Wire-to-Board Plug Connector.
