4.2mm Pitch Right-Angle Through-Hole Header

Key Features

Right-angle pins support horizontal harness exit from the board edge.

The side-entry layout can help reduce height above the PCB.

Circuit options from 2 to 24 support different harness widths.

The 4.2mm pitch suits higher-current wire-to-board connections.

White and black configurations are available according to the selected version.

Applications

Space-constrained control enclosures. Appliance PCBs with side-exit cable routing.

Power electronics and charging equipment. Industrial boards where the harness must run parallel to the PCB.

Ordering & Quotation Information

State the circuit count, required housing color, PCB thickness and available enclosure clearance. If the harness direction is critical, share the board layout or connector orientation requirement during the inquiry.

FAQ

Q1: What is the practical difference between this header and a vertical header?
A: This version routes the mating harness sideways, while a vertical header routes it upward from the PCB.

Q2: Is the header suitable for a 1.6mm PCB?
A: Yes. The applicable PCB thickness is 1.6mm.

Q3: Can I select the connector by circuit count only?
A: Circuit count is essential, but the required orientation, color and mating connector arrangement should also be confirmed.

Q4: Is this suitable for power connections?
A: The header is rated at 300V AC/DC and 8A. Final suitability depends on the complete system design and operating conditions.

Request a Quote

Share your circuit count and required cable-exit direction to quote the 4.2mm Pitch Right-Angle Through-Hole Header.
