ZTC3016 2-Vertical Straight Power Plug

Key Features

The straight plug body keeps the cable route simple at the equipment connection point.

The connector family provides two-, three-, and four-contact interface options for different power and signal requirements.

Its molded cable end is suited to assembled harnesses rather than loose field wiring.

Applications

The ZTC3016 2-Vertical Straight Power Plug is suitable for portable electrical equipment, charging units, battery-powered devices, and replacement cable harnesses using this interface style. The required contact configuration and wire range should match the equipment circuit.

Ordering & Quotation Information

Please provide the required model or product type, quantity, relevant technical configuration, and any drawing or packaging requirements for a quotation.

FAQ

Q1: Which contact options are available?
The product family provides 2-pin, 3-pin 2+1, and 4-pin 2+2 configurations.

Q2: How should buyers choose the cable range?
Select the contact configuration first, then match the cable cross-section to the required version and electrical circuit.

Q3: Is this a straight or right-angle plug?
The ZTC3016 uses a straight cable-side plug body.

Q4: Does it use a quick plug connection?
Yes. The ZTC3016 uses a quick plug connection structure.

Request a Quote

Send the required contact configuration, cable specification, quantity, and intended application for confirmation and a quotation.
